US-IHDAC-9S US-IHDAC-9S Dura-Lite Canada Evolution® Charge Air Cooler with Patented High Temperature Silicone Grommet Tube-To-Header Seal System - With Driver Side Mounts at 14 3/16" [360.4mm] (on center) and Passenger Side Mounts at 12 9/16" [319.1mm] (on center).
Evolution® Charge Air Cooler (7 Year Warranty)

US-IHDAC-9S

Description

Evolution® Charge Air Cooler with Patented High Temperature Silicone Grommet Tube-To-Header Seal System - With Driver Side Mounts at 14 3/16" [360.4mm] (on center) and Passenger Side Mounts at 12 9/16" [319.1mm] (on center).

Product Option Descriptions

Eliminator® Tube and Fin Charge Air Cooler - With Driver Side Mounts at 14 3/16" [360.4mm] (on center) and Passenger Side Mounts at 12 9/16" [319.1mm] (on center)

Eliminator® Tube and Fin Charge Air Cooler - With Driver Side Mounts at 11 13/16" [300.0mm] (on center) and Passenger Side Mounts at 11 1/2" [292.1mm] (on center)

Warranty

North American wide coverage.

Dura-Lite has maintained a less than 1% warranty return rate for over 30-years.

Dura-Lite’s warranty is not prorated and warrants the original vehicle installation for a period of 7 (seven) years or 1,000,000 (one million) miles or 1,609,000 (one million, six hundred and nine thousand) kilometers, whichever occurs first from the date of installation that its Evolution® Charge Air Coolers (the “CAC”) will remain within the allowable leak down rate specifications of the following applicable engine manufacturers under normal on-highway operating conditions: Caterpillar, Cummins, Detroit Diesel, International, Mack, Mercedes, Paccar, and Volvo (“Engine Manufacturers”).

Warranty Labour on Evolution Charge Air Coolers installed after October 1, 2023, is covered. For the first 2 (two) years from the Evolution Charge Air Cooler Installation Date, Dura-Lite will automatically pay $300.00 towards the replacement Labour for that Charge Air Cooler.

All products are tested to be 100% leak-free before they leave the manufacturing facility.

Read more...

How important is it to test my CAC ?

Product Specifications

Core Dimension - Header to Header:

Core Dimension - Over Sidepieces:

Inlet Connection OD Dimension:

Inlet Connection Note:

Outlet Connection OD Dimension:

Outlet Connection Note:

36 7/16" 20 3/8" 3" OD 4" OD
